Gardena R38Li Installation Manual

72 - English
9. TROUBLESHOOTING
9.2 Indicator lamp in the charging station
For a fully functional installation, the indicator lamp in the charging station must emit a solid green light.
If something else appears, follow the troubleshooting guide below.
There is more troubleshooting help on www.gardena.com. If you still need help with troubleshooting,
please contact GARDENA Central Service. See Memo on page 4.
Light Cause Action
Solid green light Everything in order No action required
Green flashing light The signals are good and ECO mode
is activated.
No action required. For more
information on ECO mode, see 6.6
Settings.
Blue flashing light The boundary loop is not connected
to the charging station
Check that the boundary wire
connector is fitted properly to the
charging station. See 3.5 Connecting
the boundary wire on page 29.
Break in the boundary loop Find out where the break is. Replace
the damaged section of the boundary
wire with a new loop wire and splice
using an original coupler. See
9.4 Finding breaks in the loop wire on
page 75.
Yellow flashing light The guide wire is not connected to
the charging station
Check that the guide wire connector
is properly connected to the charging
station. See 9.4 Finding breaks in the
loop wire on page 75.
Break in the guide wire Find out where the break is. Replace
the damaged section of the guide
wire with a new loop wire and splice
using an original coupler.
Red flashing light Interruption in the charging station's
antenna
Contact GARDENA Central Service.
See Memo on page 4.
Solid blue light Weak signal as the boundary wire is
too long.
No steps have to be taken if the
robotic lawnmower operates as
expected.
Shorten the boundary wire by
reducing the working area or
replacing islands with barriers the
robotic lawnmower can collide with.
Solid red light Defective circuit board in the charging
station
Contact GARDENA Central Service.
See Memo on page 4.
1157069-26,R40Li_GB.book Page 72 Wednesday, November 19, 2014 5:02 PM

Gardena R38Li Specifications

General

Type	Robotic lawn mower
Noise level	58 dB
Display type	LCD
Cutting width	170 mm
Grass catcher	No
Product color	Black, White
Cutting system	-
Number of blades	3
Maximum lawn area	380 m²
Recommended lawn area	- m²
Maximum cutting height	50 mm
Minimum cutting height	20 mm
Grass collecting volume	- L
Suitable for slope up to	25 %
Automatic base station return	Yes
Power source	Battery
Charging time	1 h
AC input voltage	18 V
Battery capacity	1.6 Ah
Battery life (max)	65 min
Power consumption per month (max)	4 kWh

Weight and Dimensions

Depth	580 mm
Width	460 mm
Height	260 mm
Weight	7400 g
