GE ApexPro TT User Manual

Technical specifications
2001989-351A ApexPro™ A-15
Storage environment
Device specifications
Bias tee specifications
Environmental specifications
Device specifications
Temperature -40 – 75°C (–40°F to 158°F)
Humidity 10 -95% non-condensing
Isolation Meets IEC 60601, classification BF, UL544 patient care, CSA 125
risk class 2G
Overall regulation < 5% no minimum load required
Maximum ripple < 100mVp-p
Cord length 305mm (12 in.)
Safety Approved to UL 544/2601.1, cUL (CSA) 22.2 #125/601.1, TUV
EN60601.1 and CE LVD
EMC Meets level B requirements of FCC part 15, CISPR11 (EN55011).
Temperature 0 - 50° C (32°F to 122°F)
Frequency 400-650MHz
Insertion loss 0.5dB, max
Isolation
 DC OUT/RF IN port
to DC IN port
 RF OUT port to DC
IN port
20dB, min
VSWR 1.3.1, max
DC voltage 30 Volts, max
DC current 1 Amp, max
RF power +20dBm, max
DC resistance 0.1 ohms
