– 47 –

Rear Cover

To access the rear cover, it is necessary to remove

the range from its installation. The rear cover is

attached using twenty-four 1/4-in. hex-head screws

(2 not shown).

Side Panel

To access the side panel, it is necessary to remove

the range from its installation. The side panel must

be removed to access the upper and lower oven

TCOs, gas lockout valve, latch assembly, and upper

oven lockout relay.

To remove the side panel:

1. On Café models, remove the control panel. (See

Touch Panel and Electronic Range Control (ERC).)

2. On Proﬁ le and GE models, remove the manifold

panel. (See Manifold Panel.)

3. Remove the rear cover. (See Rear Cover.)

4. Remove the remaining 1/4-inch hex-head

screws holding the rear of the side panel to the

frame.

(Continued next page)
