– 62 –
Pull the meat probe outlet down from the oven wall
approximately 1½ inches.
Note: When replacing the meat probe outlet, cut
the probe wires and splice the new probe using
approved heat-resistant connectors.
Meat Probe Outlet
The meat probe resistance should be between 30
k and 50 k at room temperature.
The meat probe outlet is located in the lower oven
cavity toward the front, upper left corner. To access
the probe outlet, open the lower oven door and
remove the 2 Phillips-head screws that attach the
outlet to the oven cavity.
Note: The fan blade is attached to the D-shaped
motor shaft with a left-hand thread.
Convection Fan Notes:
• The convection fan will not come on if the door
switch is open or while there is a call for heat
from the oven temperature sensor (gas burner
on).
• The fan will only start to operate 10 seconds
after the burners turn off.
• The fan has a high and low speed and will only
run in one direction.
If the convection fan is not working, check the
following:
• Check to make sure the fan shaft is not rubbing
on the oven liner.
• Check the convection fan motor resistance.
• Check for power at the convection fan terminals.
Cut Here
Cut Here
4. Remove the 13-mm nut from the convection fan
blade by securely holding the blade and turning
the nut clockwise.
13-mm Nut
To Next Page
