ADL300 - Fast installations and commissioning Pag. 31 of 52
6.4 Set Car Speed
It’s possible to configure different speeds for the car. The drive is able to manage up to 8 speeds.
See parameters:
The Slow speed is the speed used in the landing zone. When the multispeed associated with the Slow speed is selected
the slow down space is checked in order to reach this speed in proximity to the landing zone.
0 Autoselect
1 Multispeed 0
2 Multispeed 1
3 Multispeed 2
4 Multispeed 3
5 Multispeed 4
6 Multispeed 5
7 Multispeed 6
8 Multispeed 7
9 Null
When mode 0 (Autoselect) is selected, Slow speedis automatically connected to the multispeed with absolute value of
less and other than zero. If repositioning speeds with a value of less than the Slow speedare used, the multispeed
corresponding to the floor approach speed must be set.
When mode 9 (Null) is selected the floor approach spaces are never controlled. In this case the profile depends
exclusively on the multispeed selected.
Start / Rev
cmd
Mlt spd s 0
Mlt spd s 1
Mlt spd s 2
HW Enable
