gefran ADV200 Instruction Manual

Flying Shear for Roll Forming machines – Instruction manual Pag. 21 / 29
MENU
PAR
Description
UM
Type
Def
Min
Max
ACCESS
26.01.29
12056
Pos err
m
FLOAT
*
*
*
R
Position error monitor.
Command status word mapping (PAR 12052):
DIGITAL OUTPUT
BIT NUMBER
DIGITAL OUTPUT
[HEX]
DESCRIPTION
0
0x0001
Cut alarm
1
0x0002
Auto Alarm
2
0x0004
Cut length alarm
3
0x0008
Pos min alarm
4
0x0010
Pos max alarm
5
0x0020
Sync alarm
6
0x0040
Fast Stop
7
0x0080
Pos line max
8
0x0100
Not used
9
0x0200
Not used
10
0x0400
Not used
11
0x0800
Not used
12
0x1000
Not used
13
0x2000
Not used
14
0x4000
Not used
15
0x8000
Not used
Table 6: Alarm word mapping
Command status word mapping (PAR 12054):
DIGITAL OUTPUT
BIT NUMBER
DIGITAL OUTPUT
[HEX]
DESCRIPTION
0
0x0001
Enable
1
0x0002
Fast Stop
2
0x0004
Jog +
3
0x0008
Jog -
4
0x0010
Home sens
5
0x0020
Home OK
6
0x0040
Auto
7
0x0080
Cut cmd
8
0x0100
Blade close
9
0x0200
Blade open
10
0x0400
Spot cut
11
0x0800
Virtual line
12
0x1000
Virtual blade
13
0x2000
Cam status = 15 (cutting phase)
14
0x4000
Not used
15
0x8000
Not used
Table 7: Alarm word command status mapping
26.02 App Service
This menu allows the default parameters to be loaded and the speed reference destinations generated by the
application to be set.
MENU
PAR
Description
UM
Type
Def
Min
Max
ACCESS
26.02.01
11100
Load default
*
BOOL
Off
*
*
R/W
Load default application, reload only the default application values and configure
some system parameters to run the application (see Tables 2 and 4).
26.02.02
11102
Speed ref dest
*
ENUM
Speed
ref 1
*
*
R/W
