Flying Shear for Roll Forming machines – Instruction manual Pag. 27 / 29
Maximum tolerance allowed on the bar cut. If this is exceeded the alarm is tripped
by the appropriate bit of the word alarms.
Maximum permissible trolley position. If this is exceeded the alarm is tripped by the
appropriate bit of the word alarms.
Minimum permissible trolley position. If this is exceeded the alarm is tripped by the
appropriate bit of the word alarms.
Maximum misalignment allowed between the actual shear position and the drive-
generated reference. If this is exceeded the alarm is tripped by the appropriate bit of
the word alarms.
Alarm status word destination.
26.12 Virtual
The function manages the metric wheel and cut simulator. The menu allows the metric wheel specifications
and the cut command execution times to be set. See section 6 in this manual for more details.
This is used to test the machine in the absence of material. The material feed measurement signal is generated
by the same application.
Start / stop of the virtual metric wheel.
Line acceleration simulator..
Enable blade command simulator.
Simulated blade cut time.
Enabling the virtual metric wheel
26.13 About
The menu will display the version of the application installed on the drive.
