REVERSE HANDLEBARS IN THE
CLOCKWISE DIRECTION.
Fit the lever rod
in place and lock it
with the split pins
IMPORTANT
The handlebars turn through 180° in
the clockwise direction after the
linkage in place have been
detached. They must be set back in
place in the inverted position once the
handlebars have been turned.
Disconnect the gearshift rod
Disconnect the PTO control rod
The machine is equipped with a front guard to
protect the engine from damage caused by
impact.
IMPORTANT
When the handlebars are turned from
the mowing position to the normal one
(soil working direction), make sure that
the safety systems, e.i. the pin that
prevents the PTO from being engaged
when the macine is reversing and the
reverse gear from being engaged when
the PTO is engaged, operate in the
correct way.
