Technical Specifications
104 313289W
Technical Specifications
XM Plural-Component Sprayers
US Metric
Mixed ratio range 1:1–10:1 (in 0.1 increments)
Ratio tolerance range (before alarm) +/- 5%
Fluid Viscosity Range†
200-20,000 cps (heavier viscosities can be mixed using heat,
circulation, and/or pressure feeding)
Fluid filtration, standard on pump outlets* 60 mesh 238 micron
Air Filtration
40 micron main filter, 5 micron control air filter;
see pump performance charts in your Operation manual
Weight
Base sprayer (XM1L00 and XM5L00 models)
Add component weights to base sprayer weight
for your specific model weight.
742 lb 336.87 kg
Dimensions
See Dimensions, page 98.
Inlet/Outlet Sizes
Air inlet size
1.0 in. npt(f)
Fluid inlet size, without feed kits 1 1/4 npt(m)
Ambient temperature range
Operating 32–135 °F 0–57 °C
Storage 30–160 °F -1–71 °C
Maximum fluid working pressure of mixed material
50:1 5200 psi 35.8 MPa, 358 bar
70:1 6300 psi 43.5 MPa, 435 bar
Maximum fluid temperature 160 °F 71 °C
Air supply pressure range 50–150 psi 0.35–1.0 MPa, 3.5–10.3 bar
Maximum pump air set pressure
50:1 100 psi 0.68 MPa, 6.8 bar
70:1 90 psi 0.62 MPa, 6.2 bar
Maximum pump inlet fluid feed pressure 250 psi 1.7 MPa, 17 bar
Maximum air consumption at
100 psi (0.7 MPa, 7.0 bar) in scfm (m^3/min.)
70 scfm per gpm (1.96 m^3 min. per lpm)
Flow Rates
Minimum* * 1 quart per minute 0.95 liters per minute
Maximum
3 gallons per minute 11.4 liters per minute
Notes
† Heavier viscosities can be mixed using heat, circulation, and pressure feeding.
* Filter assembly is not included on some models.
* * Minimum flow rate is dependent on material being sprayed and mixing capability. Test your material specific to flow rate.
Environmental conditions rating
Indoor/outdoor use
Altitude
Up to 4000 m
Maximum relative humidity To 99% up to 130°F To 99% up to 54°C
