Parts
94 313289W
Repair and Spare Parts Reference
Ref. Part Description Qty. Part of Assembly
2 XL65D2 Motor w/linear transducer
2 Motor
2a 26C331
Linear sensor 2
Motor
60 262478
Mixer housing, no mixer; 1/2 in. ID, 3/8 nptm 2
System
61 248927
Mixer sticks; 1/2 in. x 12 element, package of 25 2
System
64 XTR724
XTR spray gun; 7250 psi; includes 519 RAC tip 1
System
64a XHD001
RAC guard, housing, replacement 1
System
64b XHDxxx
RAC tip, seal, gasket, x indicates tip size 1
System
66 L250C4
Xtreme displacement pump L250C3 w/o filter 1
XM50 "A" pump
66 25D247
Repair kit with PTFE packings 1
XM50 “A” pump
66 25D237
Repair kit with UHWPE/leather packings 1
XM50 “A” pump
66 L180C4
Xtreme displacement pump L180C3 w/o filter 1
XM70 "A" pump
66 25D245
Repair kit with PTFE packings 1
XM70 "A" pump
66 25D235
Repair kit with UHWPE/leather packings 1
XM70 "A" pump
67 L220C4
Xtreme displacement pump L220C3 w/o filter 1
XM50 "B" pump
67 25D246
Repair kit with PTFE packings 1
XM50 "B" pump
67 25D236
Repair kit with UHWPE/leather packings 1
XM50 "B" pump
67 L145C4
Xtreme displacement L145C3 w/o filter 1
XM70 "B" pump
67 25D244
Repair kit with PTFE packings 1
XM70 "B" pump
67 25D234
Repair kit with UHWPE/leather packings 1
XM70 "B" pump
67a 224458
Filter screens; 30 mesh, package of 2 (optional) 1
Pump
67a 224459
Filter screens;60 mesh, package of 2 (optional) 1
Pump
67b 244895
Filter o-rings; PTFE, package of 10 (thin) 2
Pump
67b 262484
Filter o-rings; package of 10 (medium), PTFE 2
Pump
67b 262483
Filter o-rings; PTFE, package of 10 (thick) 2
Pump
72 15T258
Wrench, Xtreme pump 1
System
75 206995
TSL; quart bottle 1
System
88 255747
Cartridge, circulation, shut-off, mix manifold valves 4-6
Shut-off/check
88a 256239
Seal kit for cartridge valves 4-6
Shut-off/check
100a 223016
Repair kit for b/p restrictor valve 2
System
147 17L724
Flash drive for USB download 1
Control
204a 15M483
Membrane shields, package of 10 1
Control
209a 121636
Solenoid valve, individual replacement valve with DIN 4
Control
223a 123412
Spare key; one pair 1
Controls
344a 123454
Control filter; 5 micron, replacement element 1
Air controls;
501a 234098
Seal kit; include soft parts, old and new dosing valve 2
Dosing valve
501b 234131
Rebuild kit; includes seals, stem, seat, and air spring 2
Dosing valve
502 245143
Sample valve; complete valve 2
Dosing valve
502a 245145
Sample valve kit; includes o-rings, ball, seat, clip 2
Dosing valve
505b 121139
Circulation valve seal; face o-ring, -210, PTFE 2
Dosing valve
507b 121399
Transducer seal; o-ring, -012, solvent resistant rubber 2
Dosing valve
508a 256238 Repair kit; includes seals, balls, seats, shut-off stems
1 Mix manifold
508b 551387 Fluid gauge, bottom mount; 10,000 psi (690 bar)
1 Mix manifold
508c 114434 Fluid gauge, back mount; 10,000 psi (690 bar)
1 Mix manifold
508d 185416 B-side strainer; 40 mesh (use tool 15T630)
1 Mix manifold
