Parts
78 313289W
Parts Varying by Pump Set
See Models, page 9, to determine which pump set is equipped on your system.
XM1_ _ _ Models
† Must purchase when installing fluid heaters on a non-heated sprayer.
‡ Not shown.
Not assembled.
Ref. Part Description
XM Plural Component Sprayer Models
XM1A00 XM1D00
52 117623 NUT, cap
66 L250C4 LOWER, A side; see English manual 311762 1 1
L250C3 LOWER, A side (without filter); see English manual 311762
67 L220C4 LOWER, B side; see English manual 311762 1 1
L220C3 LOWER, B side (without filter); see English manual 311762
69 17P248 LABEL, motor, A side 1 1
70 17P249 LABEL, motor, B side 1 1
76 121295 SCREW, cap, socket head
77
- - -
LABEL, system 1
- - - 1
80 158491 NIPPLE; 1/2 npt 2 2
81 100361 PLUG, pipe
82 15R529 BLOCK, fluid distribution
83 156684 UNION, adapter
84 121139 O-RING; PTFE
85 15J594 HOUSING, check valve
86 15J916 HANDLE, blue
87 15R380 HANDLE, green
88 255747 CARTRIDGE, valve
89 262522 CARRIAGE, remote mix manifold
92 113796 SCREW, flanged, hex head 1 1
93 111801 SCREW, cap, hex head
94 113498 VALVE, relief; 110 psi (0.76 MPa, 7.6 bar) 1 1
100 222200 VALVE, restrictor 2 2
102 156849 PIPE, nipple; 3/8 npt 2 2
108
- - -
LABEL, XM50 1 1
- - - LABEL, XM70
112
- - -
CABLE, CAN, IS, display to USB; female B/female B 1
116† 158683 ELBOW, 90 deg.
126 H42506 HOSE, coupled, 4500 psi 1 1
128
‡
224458 STRAINER, pump; 30 mesh (qty. of 2) 1 1
152 162505 UNION, swivel; 3/8 male x 1/2 female npt
153 155699 ELBOW, street; 3/8-18 npt
154 159239 NIPPLE, pipe; 1/2 x 3/8 npt
155 164672 ADAPTER
