Technical Specifications
312359R 103
Technical Specifications
XM Plural-Component Sprayers
US Metric
Mixed Ratio Range 1:1-10:1 (in 0.1 increments)
Ratio Tolerance Range (before alarm) +/- 5%
Fluid Viscosity Range†
200-20,000 cps (heavier viscosities can be mixed using heat,
circulation, and/or pressure feeding)
Fluid filtration, standard on pump outlets* 60 mesh 238 micron
Air Filtration
40 micron main filter, 5 micron control air filter;
see Pump Performance Charts, page 102
Weight
Weight: Base sprayer
(XM1L00, XM1N00 models)
Add component weights to base sprayer weight
for your specific model weight.
742 lb 336.87 kg
Dimensions
See Dimensions, page 96
Inlet/Outlet Sizes
Air inlet size
3/4 in. npt(f)
Fluid inlet size, without feed kits 1 1/4 npt(m)
Ambient temperature range
Operating
Storage
32-130 °F
30-160 °F
0-54 °C
-1-71 °C
Maximum fluid working pressure of mixed material
50:1
70:1
5200 psi
6300 psi
35.8 MPa, 358 bar
43.5 MPa, 435 bar
Maximum Pump Inlet Fluid Feed Pressure 250 psi 1.7 MPa, 17 bar
Maximum Fluid Temperature 160 °F 71 °C
Maximum pump air set pressure
50:1
70:1
100 psi
90 psi
0.68 MPa, 6.8 bar
0.62 MPa, 6.2 bar
Air Supply Pressure Range 50-150 psi 0.35-1.0 MPa, 3.5-10.3 bar
Maximum Air Consumption at
100 psi (0.7 MPa, 7.0 bar) in scfm (m^3/min.)
70 scfm per gpm (1.96 m
3
/min. per lpm)
Flow Rates
Minimum* * 1 quart per minute 0.95 liters per minute
Maximum
3 gallons per minute 11.4 liters per minute
Notes
† Heavier viscosities can be mixed using heat, circulation, and pressure feeding.
* Filter assembly is not included on some models.
* * Minimum flow rate is dependent on material being sprayed and mixing capability. Test your material specific to flow rate.
Environmental conditions rating
Indoor/outdoor use
Altitude
Up to 4000 m
Maximum relative humidity To 99% up to 130°F To 99% up to 54°C
