Basic Operation
312359R 35
Set Sprayer Limits (Optional)
For details regarding the limits setup screens, see User
Limits Setup Screens, page 83.
To set and adjust pump pressure limits and temperature
limits:
1. Select in the Enable Setup 2 screen. Follow
Enable Setup Screens, page 81, for instructions.
2. From the Home Setup screen press to jump
to the limits screens.
3. Follow the instructions in Set Pressure Limits and
Set Temperature Limits.
Set Pressure Limits
Use the following instructions to set pressure limits for
each pump that if met will issue an advisory and/or
warning.
To set pressure limits, press and to move
through each field, and press to make a field
selectable. Press to scroll through each
pressure digit, and press and to scroll
through the optional values. Continue this process until
you reach the desired pressure limit. Press to
save.
The B pump pressure always runs 10-20% higher than
the A pump pressure.
Set Temperature Limits
Use the following instructions to set temperature limits
that if met will issue an advisory and/or warning.
Press to move to the temperature limits screen.
To set temperature limits, press and to move
through each field, and press to make a field
selectable. Press to scroll through each
temperature digit, and press and to scroll
through the optional values. Continue this process until
you reach your desired temperature limit. Press to
save the value.
The allowable range for the temperature setpoint is 34° -
160° F (1° - 71° C).
