Grant GSD1 User Manual

3 Dimensions & Fixing Intervals
8
Dimensions &
Fixing Intervals
3.1 On-roof Installation
Position of Roof Anchors and Mounting Rails
1187mm
3561mm
5935mm
4205mm
4748mm
2374mm
~800mm ~700mm
~1300mm
~1700mm
~1100mm ~1100mm ~1100mm
~1700mm ~1700mm
~1300mm ~1300mm ~1300mm~1300mm
~700mm~200mm max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
max.
500mm
~200mm
~1800mm~1800mm~1800mm
~1800mm
60mm60mm60mm~900mm60mm
60mm
~1800mm60mm
2042mm 2042mm
2042mm
2042mm
2042mm
Figure 1: 1 collector (portrait) Figure 2: 2 collectors (portrait)
Figure 3: 3 collectors (portrait)
Figure 5: 5 collectors (portrait)
Figure 6: 2 collectors (landscape)
Figure 4: 4 collectors (portrait)
1142mm
