Häfele dialock DTSH User Manual

Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
45
English
Installation Instructions
Tools
Tools Cat. No.
Locking ring pliers (for fitting locking
ring to inner square spindle)
917.90.900
SW3 T-handle for
grub screws of lever handle aperture part
and removing the inner hood
006.32.013
DTSH DIN drilling jig 917.90.005
Router cutter for breakthrough to lock
nut
Ø 25 mm 910.54.995
Router cutter
with centring pin
only needed for
mortise lock with
mergency open-
ing logging)
Fig. 5
Ø 32 mm 910.54.997
Stop for router cutter
(only needed for mor-
tise lock with emer-
gency opening log)
Fig. 6
32 mm 001.28.129
Drill bits
(cable leadthrough)
Fig. 7
13 mm 001.41.351
Drill
(Fastening spots)
8 mm 001.41.248
Drill
Cross slot screwdriver size 2 006.28.382
