Häfele dialock DTSH User Manual

Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
41
English
Installation Instructions
Accessories (not incl. in the scope of delivery) Cat. No.
Mounting sets for DTSH
No. Door thickness Consisting of
1 37 – 47 mm 1 inner square spindle L=100mm 917.90.242
4 countersunk head screws
DIN 965 M4x30
für DTSH FH 917.90.121
2 47 – 57 mm 1 inner square spindle L=110mm 917.90.244
4 countersunk head screws
DIN 965 M4x40
for DTSH FH 917.90.122
3 57 – 67 mm 1 inner square spindle L=120mm 917.90.246
4 countersunk head screws
DIN 965 M4x50
for DTSH FH 917.90.124
4 67 – 77 mm 1 inner square spindle L=130mm 917.90.248
4 countersunk head screws
DIN 965 M4x60
for DTSH FH 917.90.126
5 77 – 87 mm 1 inner square spindle L=130mm 917.90.250
4 countersunk head screws
DIN 965 M4x70
for DTSH FH 917.90.128
6 87 – 97 mm 1 inner square spindle L=160mm 917.90.251
4 countersunk head screws
DIN 965 M4x80
for DTSH FH 917.90.130
7 97 – 107 mm 1 inner square spindle L=160mm on request
4 countersunk head screws
DIN 965 M4x90
for DTSH FH on request
