Häfele dialock DTSH User Manual

40
English
Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
Installation Instructions
Accessories (not included in the scope of delivery)
Accessories (not incl. in the scope of delivery) Cat. No.
Black plastic spacer plate 917.90.492
Stainless steel spacer plate for DTSH FH 917.90.216
Profile cylinder cover (break-open seal),
plastic, black
Optional:
Stainless steel matt
Stainless steel polished
Brass polished
25 pieces 917.90.483
917.90.480
917.90.481
917.90.488
User key: Different models
4 x 1.5 V batteries, size AA Mignon type E91
Energizer
®
Ultra+
910.54.980
Lever handle aperture part: Different models.
DTSH FH: Only supplied models may be used
(see catalogue).
Single profile cylinder:
Length depends on door leaf thickness.
Single profile cylinder must be fitted with DTSH FH!
Mortise lock: Different models
DTSH: Locks in accordance with DIN 18251.
DTSH FH: Locks in accordance with DIN 18273.
