Häfele dialock DTSH User Manual

Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
39
English
Installation Instructions
Always follow the instructions in the "Start-up and maintenance"
guide when starting up (assigning keys)!
Scope of delivery
1 External module฀
1 Internal module฀
Small parts bag with ฀
profile cylinder cover (break-open seal)
1 Promaseal strip (DTSH FH only)฀
Profile cylinder coverFig. 1
Profile cylinder
cover
Rotary knob
(fixed at hood)
Internal module External moduleFig. 3
Promaseal stripFig. 2
