HDE 16.05.2022 732.22.110
42
FAN 30 antenna
Accessories
3.3 Functions
Latchbolt lock operation / self-locking action (= factory setting)
In latchbolt lock operation, the furniture lock is unlocked during the open time of 3 seconds and
locks again automatically once the open time has elapsed (self-locking action).
Deadbolt lock operation (permanent open)
In deadbolt lock operation, the furniture lock is permanently unlocked (permanent open). The
furniture lock is locked by presenting one of the user keys that is authorised for deadbolt lock
operation again.
EFL 30C (with additional feedback contact for door status indication)
In conjunction with the additional feedback contact in the EFL 30C and a corresponding macro,
the locking status of the access point can be detected independently of the lock’s locking
status.
This allows the EFL 30, for example, to send a signal to sound the alarm.
Feature Value
Degree of protection IP 67
Transponder technology Tag-it, MIFARE Classic EV 1, MIFARE DESFire EV1 and EV2.
For the Dialock software applications, the transponders used
must be qualified and coded by Häfele.
Read range ≤ 25 mm
Environment Not suitable for assembly:
• in metal
• in metal-coated furniture
• behind mirrored surfaces
Minimum distance between two
antennas
250 mm
Connector plug MCX (coaxial connector)
Feature Description
Programming key card • Card for granting access authorisations
Clearing key card • Card for clearing access authorisations
User key • Electronic key
• different versions possible: Key Card, Key Tag,
Key Fob, Key Bracelet
Macros • On request
