60 HARDI
®
COMMANDER OPERATOR’S MANUAL
Emergency operation of the sprayer
The boom
In case of power failure, the boom can be operated
manually as described below:
1. Unscrew top part A from solenoid valve. Notice the
small pin in the hollow of the valve.
2. The boom can now be operated by depressing the
individual pins in the valves. Use a proper tool for
this purpose.
Remember to reset the system to original
setting.
Cause
The problem may be due to a blown fuse. One spare
fuse is located inside the junction box.
A
ECP operating unit
In case of power failure it is possible to operate all
functions of the operating unit manually. First discon-
nect the multi plug from the control box. Now manually
turn the emergency control knobs.
The problem may be due to a blown fuse. An extra fuse
is placed inside the box.
Fuse type: 6.3 A
Emergency operation
