Fuses
White or
Blue
Black
Blue &
Brown
Black
Blue
Brown
Filler light
Auxillary 12V output, fused
Power cable set
Working lights
Selector switch
Blue Brown
Black
S2 function:
Open: Working light cannot
be activated unless parking
light is on.
Closed: Working light
independent of parking
light.
Connected directly to battery
Pin 2 - Black
Pin 6 - Brown
Pin 4 - Red
Pin 5 - Green
Pin 3 - Yellow
Pin 7 - Blue
Pin 1 - White
Note:
Working light on/off. The center
tab of the selector switch must
be connected to pin 2. In addition,
pin 2 on the tractor must be
connected to one of the working
light switches in the cabin.
