Harman P42i-TC Installation Manual

Harman® • P42i Pellet Insert Installation Manual • 2023 -___ • 08/2310 8742-901D
4 4
Termination Location and Vent Information
A. Vent Termination Requirements
V
=Vent Terminal
A
=Air Supply Inlet
=Area where termination is not permitted
Door
Sidewalk
Fixed
Closed
Openable
Openable
Fixed
Closed
Inside Corner
Detail
Porch or
Openable
Deck
or Fixed
WARNING: Venting terminals must not be recessed into a
wall or siding.
NOTE:OnlyPLorLventpipewallpass-throughsandre
stops should be used when venting through combustible
materials.
NOTE:Alwaystakeintoconsiderationthea󰀨ectthe
prevailing wind direction or other wind currents will cause
withyashand/orsmokewhenplacingthetermination.
In addition, the following must be observed:
A. The clearance above grade must be a minimum of 12".
B. The clearance to a window or door that may be opened
must be a minimum of 48" to the side and 48" below
thewindow/door,and12"abovethewindow/door.(with
outside air installed, 9” to side and below)
C. A 12" clearance to a permanently closed window is
recommended to prevent condensation on the window.
D.Theverticalclearancetoaventilatedso󰀩tlocated
above the terminal within a horizontal distance of 2 feet
(607mm)fromthecenter-lineoftheterminalmustbea
minimum of 18".
E.Theclearancetoanunventilatedso󰀩tmustbea
minimum of 12".
F. The clearance to an outside corner is 11" from center of
pipe.
G. The clearance to an inside corner is 12".
H.Aventmustnotbeinstalledwithin3feet(914mm)
aboveagasmeter/regulatorassemblywhenmeasured
fromthehorizontalcenter-lineoftheregulator.
I.Theclearancetoserviceregulatorventoutletmustbea
minimum of 6 feet.
J.Theclearancetoanon-mechanicalairsupplyinletto
the building or the combustion air inlet to any other
appliancemustbeaminimumof48”.
K. The clearance to a mechanical air supply inlet must be
aminimumof10feet.(with outside air installed, 6
feet)
L.Theclearanceaboveapavedsidewalkorapaved
driveway located on public property must be a minimum
of 7 feet.
M.Theclearanceunderaveranda,porch,deckorbalcony
must be a minimum of 12". (B. also)
NOTE:Theclearancetovegetationandotherexterior
combustiblessuchasmulchis36”asmeasuredfromthe
centeroftheoutletorcap.This36”radiuscontinuesto
grade or a minimum of 7 feet below the outlet.
CertainCanadianandorLocalcodesorregulationsmay
requiredi󰀨erentclearances.
Aventshallnotterminatedirectlyaboveaside-walk
or paved driveway which is located between two
single family dwellings and serves both dwellings.
Onlypermittedifveranda,porch,deck,orbalconyisfully
openonaminimumof2sidesbeneaththeoor.
See NFPA 211 for more installation clearance reductions
when using outside air.
NOTE: In Canada, where passage through a wall or
partition of combustible construction is desired, the
installation shall conform to CAN/CSA-B365.
Chimney connector shall not pass through an attic or roof
space, closet or similar concealed space, or a oor or ceiling.
