Harman P42i-TC Installation Manual

Harman® • P42i Pellet Insert Installation Manual • 2023 -___ • 08/236 8742-901D
A . Design and Installation Considerations
1. Appliance Location
NOTICE: Check building codes prior to installation.
• InstallationMUSTcomplywithlocal,regional,stateand
national codes and regulations.
• Consult insurance carrier, local building inspector, re
o󰀩cialsorauthoritieshavingjurisdictionoverrestrictions,
installation inspection and permits.
Itisagoodideatoplanyourinstallationonpaper,usingexact
measurementsfor clearances andoorprotection, before
actually beginning the installation
Considerationmustbegivento:
• Safety,convenience,tra󰀩cow
• Placement of the chimney and chimney connector.
• If you are not using an existing chimney, place the
appliance where there will be a clear passage for a
factory-builtlistedchimneythroughtheceilingandroof.
• Installing an optional outside air kit would a󰀨ect the
location of the vent termination.
Suitable replaces for installation:
• MasonryFireplace
• ExistingFactoryBuiltWoodBurningFireplace
• Harman®ZeroClearanceCabinet-Part#1-00-574323
EXCEPTION:Masonryorsteel,includingthedamperplate,
may be removed from the smoke shelf and adjacent damper
frame if necessary to accommodate a chimney liner,
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 2.1
2 2
Getting Started
provided that their removal will not weaken the structure of
the replace and chimney, and will not reduce protection
for combustible materials to less than that required by the
National Building Code.
Sincepelletexhaust cancontainash,sootorsparks,you
mustconsiderthelocationof:
• Windows
• AirIntakes
• Air Conditioner
• Overhangs,so󰀩ts,porchroofs,adjacentwalls
• Landscaping,vegetation
When locating vent and venting termination, vent above
roof line when possible.
Warning! Risk of Fire Damaged parts could impair safe
operation. Do NOT install damaged, incomplete or substitute
components.
NOTICE: Locating the appliance in a location of considerable
air movement can cause intermittent smoke spillage from
appliance. Do not locate appliance near:
• Frequently open doors
• Central heat outlets or returns
Installation and service of this
appliance should be performed by
qualiedpersonnel.Hearth&Home
Technologies recommends HHT
Factory Trained or NFI Certied
professionals.
