Harman P42i-TC Installation Manual

Harman® • P42i Pellet Insert Installation Manual • 2023 -___ • 08/238 8742-901D
3 3
Clearances
A. Appliance Dimension Diagram
Dimensionsareactualappliancedimensions.Useforreferenceonly.
Figure 3.1
42”
25-3/8”
30-7/8”
20”
24”
27-3/4”
12-3/4”
15”
7/8”
11-5/8”
12-3/8”
To Top Edge
To Front Door Glass
24-7/8”
23-3/4”
Measured from steel stove body

Harman P42i-TC Specifications

General

Brand	Harman
Model	P42i-TC
Category	Indoor Fireplace
Language	English
