112 II Technical Information
II – 1 Installation and Electrical Connection
II – 1 Installation and Electrical
Connection
Items Supplied
POSITIP 880 Display Unit
Tilt/Swivel Mount
Power connector
User's Manual
Mounting Location
Locate the unit in a well ventilated area such that it may be easily
accessed during normal operation.
Installation
M4 screws are used to secure POSITIP 880 from below. For the hole
locations: see chapter II-8 Dimensions.
Electrical connection
There are no serviceable items within this unit. Therefore,
the POSITIP 880 should not be opened.
The power cord is the primary means of disconnect. The
length of the power cord is not to exceed 3 meters.
Connect a protective ground to the protective conductor
terminal on the rear of the unit.
This connection must never be interrupted.
Do not engage or disengage any connections while the
unit is under power. Damage to internal components may
result.
Use only original replacement fuses.
The equipment shall be connected for its intended
purpose, or not connected for any use whatsoever.
