POSITIP 880 141
II – 7 Specifications for Turning
II – 7 Specifications for Turning
POSITIP 880 Data
Axes Up to 6 axes from A to Z, Z
0
, Z
S
Encoder inputs 6 x 11 µA
PP
, 1 V
PP
or EnDat (switchable); input frequency max. 100 kHz for
incremental or absolute HEIDENHAIN encoders
 Signal period:
0.128 µm, 2 µm, 4 µm, 10 µm, 20 µm, 40 µm, 100 µm, 10240 µm
 Line count:
9000/18000/36000
Subdivision factor Max. 1024-fold
Display step Linear axes: 1 mm to 0.005 µm
Rotary axes: 1° to 0.0001° (00°00’01”)
Display Color flat-panel display for position values, dialog and input display, graphic
functions, graphic positioning aid
 Multi-lingual text
 Status display:
Tool number
Diameter display Ø
Sum display
Functions  REF reference-mark evaluation for distance-coded or single reference marks
 Distance-to-go mode, nominal position input (absolute or incremental)
 Contour monitoring with magnify function
 Scaling factor
 HELP: On-screen operating instructions
 INFO: Calculator, taper calculator, user and operating parameters
 1 datum point, 99 tools
 Freezing tool position for back-off
 Oversize allowance
Programming Up to 999 program blocks in each program; sub programming capability; teach-
in programming
 Cycles:
Lines, arcs, chamfers, multipass turning, blend
Error Compensation Linear and non-linear, up to 128 measuring points
Data interface  Serial:
RS-232-C/V.24 300 to 115 200 baud
For output of programs, measured values and parameters;
For input of programs and parameters
 Parallel:
Centronics for output of measured values
Switching inputs/outputs Upon request (via separate AMI input/output unit)
