HEIDENHAIN POSITIP 880 User Manual

POSITIP 880 129
II – 3 Encoders and Measured Value Display
Setting the display step with rotary encoders
With rotary encoders, the display step depends on the
 line count of the encoder and the
 angle display step
Both parameters are entered separately for each rotary axis.
Example settings for HEIDENHAIN rotary encoders
Encoder Line count Reference marks
ROD 250, RON 255 9 000/18 000 1
ROD 250C, RON 255C 9 000 500
ROD 250C, ROD 255C
ROD 700C, RON 705C
RON 706C
18 000 1 000
ROD 700C, ROD 800C 36 000 1 000
