Multiple-Axis Machining | FUNCTION TCPM (option 9)
13
578
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
REFPNT CENTER-CENTER
You can use the REFPNT CENTER-CENTER variant to machine parts
with a tool whose tip is used as a reference point when executing
NC programs generated in a CAD/CAM software where the paths
reference the center of the cutting edge radius instead of the tool
tip.
Previously, this functionality could only be achieved by shortening
the tool with DL. The variant with REFPNT CENTER-CENTER is
advantageous in that the control knows the true tool length .
If you use REFPNT CENTER-CENTER, to program pocket milling
cycles, the control generates an error message.
Example
...
13 FUNCTION TCPM F TCP AXIS SPAT PATHCTRL AXIS
REFPNT TIP-TIP
Both the tool reference point and the center of rotation are
located at the tool tip.
14 FUNCTION TCPM F TCP AXIS POS PATHCTRL AXIS
REFPNT CENTER-CENTER
Both the tool reference point and the center of rotation are
located at the center of the cutting-edge radius.
...
Resetting FUNCTION TCPM
Use FUNCTION RESET TCPM to explicitly cancel
the function within a program.
When you select a new NC program in the Program
run, single block or Program run, full sequence
operating modes, the control automatically cancels the
TCPM function.
Example
...
25 FUNCTION RESET TCPM
Reset FUNCTION TCPM
...
