Programming Q Parameters | String parameters
10
448
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Reading system data
With the function SYSSTR you can read system data and store
them in string parameters. You select the system data through a
group number (ID) and a number.
Entering IDX and DAT is not required.
Group name, ID no. Number Meaning
Program information, 10010 1 Path of the current main program or pallet program
3
Path of the cycle selected with CYCL DEF 12 PGM
CALL
10
Path of the program selected with SEL PGM
Channel data, 10025 1 Channel name
Values programmed in the tool
call, 10060
1 Tool name
Current system time, 10321 1 - 16 1: DD.MM.YYYY hh:mm:ss
2 and 16: DD.MM.YYYY hh:mm
3: DD.MM.YY hh:mm
4: YYYY-MM-DD hh:mm:ss
5 and 6: YYYY-MM-DD hh:mm
7: YY-MM-DD hh:mm
8 and 9: DD.MM.YYYY
10: DD.MM.YY
11: YYYY-MM-DD
12: YY-MM-DD
13 and 14: hh:mm:ss
15: hh:mm
Touch-probe data, 10350 50 Probe type of the active touch probe TS
70 Probe type of the active touch probe TT
73 Key name of the active touch probe TT from MP
activeTT
Data for pallet machining, 10510 1 Pallet name
2 Path of the selected pallet table
NC software version, 10630 10 Version identifier of the NC software version
Tool data, 10950 1 Tool name
2 DOC entry of the tool
4 Tool-carrier kinematics
