20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
793
20.3 Technical Information
Explanation of symbols
■
Default
□
Axis option
1 Advanced Function Set 1
2 Advanced Function Set 2
x Software option, except Advanced Function Set 1 and Advanced Function Set 2
Specifications
Components
■
Operating panel
■
TFT color flat-panel display with soft keys
or TFT color flat-panel display with touchscreen
Program memory
■
2 GB
■
As fine as 0.1 µm for linear axes
■
As fine as 0.01 µm for linear axes (with option 23)
Input resolution and display
step
■
Up to 0.0001° for rotary axes
■
Up to 0.000 01° for rotary axes (with option 23)
Input range
■
Maximum 999 999 999 mm or 999 999 999°
■
Linear in 4 axesInterpolation
■
Circular in 2 axes
■
Helical: superimposition of circular and straight paths
Block processing time
3-D straight line without radius
compensation
■
1.5 ms
■
Position loop resolution: Signal period of the position encoder/1024Axis feedback control
■
Cycle time of position controller: 3 ms
■
Cycle time of speed controller: 200 µs
Range of traverse
■
Maximum 100 m (3937 inches)
Spindle speed
■
Maximum 100,000 rpm (analog speed command signal)
Error compensation
■
Linear and nonlinear axis error, backlash, reversal peaks during circular
movements, thermal expansion
■
Static friction
■
One each RS-232-C /V.24 max. 115 kilobaud
■
Expanded data interface with LSV-2 protocol for remote operation of
the control through the data interface with the HEIDENHAIN software
TNCremo
Data interfaces
■
Ethernet interface 1000 BaseT
■
5 x USB (1 x front USB 2.0; 4 x rear USB 3.0)
Ambient temperature
■
Operation: 5 °C to +45 °C
■
Storage: –35 °C to +65 °C
