HEIDENHAIN TNC 620 Programming Station User Manual

Fundamentals, File Management | File management: Basics
4
168
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
4.3 File management: Basics
Files
Files in the control Type
Programs
in HEIDENHAIN format
in DIN/ISO format
.H
.I
Compatible programs
HEIDENHAIN unit programs
HEIDENHAIN contour programs
.HU
.HC
Tables for
Tools
Tool changers
Datums
Points
Presets
Touch probes
Backup files
Dependent data (e.g. structure items)
Freely definable tables
Pallets
.T
.TCH
.D
.PNT
.PR
.TP
.BAK
.DEP
.TAB
.P
Text as
ASCII files
Log files
Help files
.A
.TXT
.CHM
CAD files as
ASCII files
.DXF
.IGES
.STEP
When you write a part program on the control, you must first enter
a program name. The control saves the program to the internal
memory as a file with the same name. The control can also save
texts and tables as files.
The control provides a special file management window in which
you can easily find and manage your files. Here you can call, copy,
rename and erase files.
With the control you can manage and save files up to a total size of
2 GB.
Depending on the setting, the control generates backup
files with the extension *.bak after editing and saving of
NC programs. This reduces the available memory space.
