HEIDENHAIN TNC 620 Programming Station User Manual

Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
822
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Comparison: Differences in programming
Function TNC 620 iTNC 530
Switching the operating mode while
a block is being edited
Permitted Permitted
File handling:
Save file function Available Available
Save file as function Available Available
Discard changes Available Available
File management:
Mouse operation Available Available
Sorting function Available Available
Entry of name
Opens Select file pop-up
window
Synchronizes the cursor
Support of key combinations Not available Available
Favorites Management Not available Available
Configuration of column
structure
Not available Available
Soft-key arrangement Slightly different Slightly different
Skip block function Available Available
Selecting a tool from the table Selection via split-screen menu Selection in a pop-up window
Programming special functions with
the SPEC FCT key
Pressing the key opens a soft-key
row as a submenu. To exit the
submenu, press the SPEC FCT key
again; then the control shows the
last active soft-key row
Pressing the key adds the soft-
key row as the last row. To exit the
menu, press the SPEC FCT key
again; then the control shows the
last active soft-key row
Programming approach and depar-
ture motions with the APPR DEP
key
Pressing the key opens a soft-key
row as a submenu. To exit the
submenu, press the APPR DEP key
again; then the control shows the
last active soft-key row
Pressing the key adds the soft-
key row as the last row. To exit the
menu, press the APPR DEP key
again; then the control shows the
last active soft-key row
Pressing the hard key END with
active CYCLE DEF and TOUCH
PROBE menus
Terminates the editing process and
calls the file manager
Exits the respective menu
Calling the file manager while the
CYCLE DEF and TOUCH PROBE
menus are active
Terminates the editing process and
calls the file manager. The respec-
tive soft-key row remains selected
when the file manager is exited
Key non-functional error message
Calling the file manager while CYCL
CALL, SPEC FCT, PGM CALL and
APPR/DEP menus are active
Terminates the editing process and
calls the file manager. The respec-
tive soft-key row remains selected
when the file manager is exited
Terminates the editing process and
calls the file manager. The basic
soft-key row is selected when the
file manager is exited
