HEIDENHAIN TNC 620 Programming Station User Manual

Subprograms and Program Section Repeats | Nesting
9
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
357
Subprogram within a subprogram
Example
0 BEGIN PGM UPGMS MM
...
17 CALL LBL "UP1"
Call the subprogram marked with LBL SP1
...
35 L Z+100 R0 FMAX M2
Last program block of the main program with M2
36 LBL "UP1"
Beginning of subprogram SP1
...
39 CALL LBL 2
Call the subprogram marked with LBL 2
...
45 LBL 0
End of subprogram 1
46 LBL 2
Beginning of subprogram 2
...
62 LBL 0
End of subprogram 2
63 END PGM SUBPGMS MM
Program execution
1 Main program UPGMS is executed up to block 17.
2 Subprogram SP1 is called, and executed up to block 39.
3 Subprogram 2 is called, and executed up to block 62. End of
subprogram 2 and return jump to the subprogram from which it
was called.
4 Subprogram 1 is called, and executed from block 40 up to block
45. End of subprogram 1 and return jump to the main program
UPGMS.
5 Main program UPGMS is executed from block 18 up to block 35.
Return jump to block 1 and end of program.
