HEIDENHAIN TNC 620 Programming Station User Manual

Special Functions | Working with the parallel axes U, V and W
12
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
501
FUNCTION PARAXCOMP DISPLAY
Example
13 FUNCTION PARAXCOMP DISPLAY W
Use the PARAXCOMP DISPLAY function to activate the display
function for parallel axis movements. The control includes
movements of the parallel axis in the position display of the
associated principal axis (sum display). Therefore, the position
display of the principal axis always displays the relative distance
from the tool to the workpiece, regardless of whether you move
the principal axis or the minor axis.
Proceed as follows for the definition:
Show the soft-key row with special functions
Press the PROGRAM FUNCTIONS soft key
Select FUNCTION PARAX
Select FUNCTION PARAXCOMP
Select the FUNCTION PARAXCOMP DISPLAY
function
Define the parallel axis whose movements the
control is to take into account in the position
display of the associated principal axis
