HEIDENHAIN TNC 620 Programming Station User Manual

First Steps with the TNC 620 | Workpiece setup
1
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
83
1.6 Workpiece setup
Selecting the correct operating mode
Workpieces are set up in the Manual operation or Electronic
handwheel mode
Press the operating mode key
The control switches to the Manual operation
mode.
Further information on this topic
The operating mode Manual operation
Further information: "Moving the machine axes", page 625
Clamping the workpiece
Mount the workpiece with a fixture on the machine table. If you
have a 3-D touch probe on your machine, then you do not need to
clamp the workpiece parallel to the axes.
If you do not have a 3-D touch probe available, you have to align the
workpiece so that it is fixed with its edges parallel to the machine
axes.
Further information on this topic
Presetting with a 3-D touch probe
Further information: "Presetting with a 3-D touch probe (option
number 17)", page 676
Presetting without 3-D touch probe
Further information: "Presetting without a 3-D touch probe",
page 652
