Introduction | Remote Desktop Manager (option 133)
2
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
119
Setting Meaning Input
Full-screen mode or User-
defined window size:
Size of the connection window Required
Permit further connections
(share)
Enable access to the VNC server also by other VNC connections Required
View only
The external computer cannot be operated in display mode Required
Entries in the Advanced
options area
Available only to authorized specialists Optional
With VNC, the screen of the external computer is mirrored
directly. The active desktop on the external computer is not locked
automatically.
With a VNC connection, it is also possible to completely shut down
the external computer via the Windows menu. As the computer
cannot be rebooted over a connection, it must actually be switched
off and on again.
Shutting down or rebooting an external computer
NOTICE
Caution: Data may be lost!
If the external computer is not shut down properly, data may be
irreversibly damaged or deleted.
Configure automatic shutdown of the Windows computer
Proceed as follows to configure the control:
Press the DIADUR key to open the HeROS menu
Select Remote Desktop Manager
The control opens the Remote Desktop Manager.
Press New connection
Press Switch-off/restart of a computer
The control opens the Edit the connection pop-up window.
Edit the connection
Setting Meaning Input
Connection name:
Name of the connection in the Remote Desktop Manager Required
Restarting after end of
connection:
Not necessary with this connection –
Automatic starting upon
login
Not necessary with this connection –
Add to favorites
Connection icon in the task bar:
Single click with the left mouse button
The control switches to the desktop of the connection.
Single click with the right mouse button
The control displays the connection menu.
Required
Move to the following
workspace
Not active with this connection –
