Tools | Tool data
6
254
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Tool usage test
Requirements
Refer to your machine manual.
The tool usage test function must be enabled by your
machine tool builder.
To conduct a tool usage test, you must activate Create tool usage
files in the MOD menu.
Further information: "Tool usage file", page 745
Generating a tool usage file
Depending on the setting in the MOD menu, you have the
following options for generating the tool usage file:
Completely simulate the NC program in the Test Run operating
mode
Completely run the NC program in the Program Run, Full
Sequence/Single Block operating modes
In the Test Run operating mode, press the
GENERATE TOOL USAGE FILE soft key (also possible without
simulation)
The tool usage file generated is in the same directory as the NC
program. It contains the following information:
Column Meaning
TOKEN TOOL: Tool usage time per tool call. The
entries are listed in chronological order.
TTOTAL: Total usage time of a tool
STOTAL: Call of a subprogram. The
entries are listed in chronological order.
TIMETOTAL: The total machining time
of the NC program is entered in the
WTIME column. In the PATH column
the control saves the path name of
the corresponding NC program. The
TIME column shows the sum of all TIME
entries (feed time without rapid traverse
movements). The control sets all other
columns to 0
TOOLFILE: In the PATH column, the
control saves the path name of the tool
table with which you conducted the test
run. This enables the control during the
actual tool usage test to detect whether
you performed the test run with TOOL.T
TNR Tool number (–1: Tool not inserted yet)
IDX
Tool index
NAME
Tool name from the tool table
TIME
Tool usage time in seconds (feed time
without rapid traverse movements)
