Miscellaneous Functions | Miscellaneous functions for program run inspection, spindle and coolant
11
470
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
11.2 Miscellaneous functions for program run
inspection, spindle and coolant
Overview
Refer to your machine manual.
The machine manufacturer can influence the behavior of
the miscellaneous functions described below.
M Effect Effective at block Start End
M0 Program STOP
Spindle STOP
■
M1 Optional program STOP
Spindle STOP if necessary
Coolant OFF if necessary (function
defined by the machine tool builder)
■
M2 STOP program run
Spindle STOP
Coolant off
Return jump to block 1
Clear status display
Functional scope depends on machine
parameter
resetAt (no. 100901)
■
M3 Spindle ON clockwise
■
M4 Spindle ON counterclockwise
■
M5 Spindle STOP
■
M6 Tool change
Spindle STOP
Program STOP
■
M8 Coolant ON
■
M9 Coolant OFF
■
M13 Spindle ON clockwise
Coolant ON
■
M14 Spindle ON counterclockwise
Coolant ON
■
M30 Same as M2
■
