Programming Q Parameters | Preassigned Q parameters

460

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Tool measurement with the BLUM laser Parameter value

Reserved Q190

Reserved Q191

Reserved Q192

Reserved Q193

Reserved for internal use Parameter value

Marker for cycles Q195

Marker for cycles Q196

Marker for cycles (machining patterns) Q197

Number of the last active measuring cycle Q198

Status of tool measurement with TT Parameter value

Tool within tolerance Q199 = 0.0

Tool is worn (LTOL/RTOL is exceeded) Q199 = 1.0

Tool is broken (LBREAK/RBREAK is exceed-

ed)

Q199 = 2.0
