5. Parameter Setting
5-7
5.2 Motor and System Parameter (Motor Parameter: P1--)
These parameters are used to set the motor and the system. User must set parameters to suit the
motor and the system prior to use.
Menu Menu title Description Unit Setting range Default
*P1-01 Motor ID Motor ID 0 ~ 99 0
ID Model ID Model ID Model ID Model ID Model
0
Individual
input
20 TF05 40 LF03 60 KN03 80 LN03
1 21 TF09 41 LF06 61 KN05 81 LN06
2 22 TF13 42 LF09 62 KN06 82 LN09
3 23 TF20 43 LF12 63 KN07 83 LN12
4 24 TF30 44 LF20 64 KN06A 84 LN12A
5 CKZ5 25 TF44 45 LF30 65 KN11 85 LN20
6 CK01 26 TF09-05 46 66 KN16 86 LN30
7 27 47 67 KN22 87 LN40
8 CK02 28 48 68 KN22A 88 TN110
9 CK04 29 49 69 KN35 89 TN150
10 30 KF08 50 CN04A 70 TN05 90
11 CN01 31 KF10 51 CN06 71 TN09 91
12 CN02 32 KF15 52 CN08 72 TN13 92
13 CN03 33 KF20 53 CN10 73 TN17 93
14 CN04 34 KF35 54 CN09 74 TN20 94
15 CN05 35 KF50 55 CN15 75 TN30 95
16 36 56 CN22 76 TN44 96
17 37 57 CN30 77 TN75 97
18 38 58 CN30A 78 TN55 98
19 39 59 CN50 79 KN55 99
If the motor used is in the above table, input motor ID to [Motor ID(P1-01)].
In such case, [JM (P1-02)], [KT (P1-03)], [Ls(Phase) (P1-04)], [Rs(Phase) (P1-05)], [Is(Rated)
(P1-06)], [SPD(Max) (P1-07)], [SPD(Rated) (P1-08)], [Pole Number (P1-09)] among the set
values are automatically set, and individual editing is not allowed.
If the motor used is not shown on the above table, or if it is desired to change one or more of
the set values related to the motor, input 0 to [Motor ID (P1-01)].
