HIKVISION DS-2DE2A404IW-DE3/W User Manual

User Manual of Network PTZ Camera
© Hikvision
39
5.2 Basic Event Configuration
Purpose:
This section explains how to configure the network camera to respond to alarm events, including
motion detection, video tampering alarm input, alarm output and exception. These events can
trigger the alarm actions, such as Send Email, Notify Surveillance Center, etc.
For example, when motion detection is triggered, the network camera sends a notification to an
e-mail address.
 On the event configuration page, click to show the PTZ control panel or click to hide it.
 Click the direction buttons to control the pan/tilt movements.
 Click the zoom/iris/focus buttons to realize lens control.
 The functions vary depending on different camera models.
5.2.1 Configuring Motion Detection
Purpose:
Motion detection is a feature which can trigger alarm actions and actions of recording videos
when the motion occurred in the surveillance scene.
Steps:
1. Enter the motion detection setting interface:
Configuration > Event > Basic Event > Motion Detection
2. Check the checkbox of the Enable Motion Detection to enable this function.
You can check the Enable Motion Detection in PTZ Control checkbox and when the speed
dome is performing PTZ action, motion detection can also trigger alarm.
You can check the Enable Dynamic Analysis for Motion checkbox if you want the detected
object get marked with rectangle in the live view.
3. Select the configuration mode as Normal or Expert and set the corresponding motion
detection parameters.
 Normal

HIKVISION DS-2DE2A404IW-DE3/W Specifications

General

Brand	HIKVISION
Model	DS-2DE2A404IW-DE3/W
Category	Security Camera
Language	English
