Digital Video Recorder User Manual
117

Up to 8 periods can be configured for each day. And the time periods cannot be overlapped
each other.

In the time table of the channel, both holiday schedule and normal day schedule are
displayed.

Repeat the above step 4 to set Holiday schedule for other channels. If the holiday schedule
can also be used to other channels, click Copy and choose the channel you want to apply
the settings.
5.8 Configuring Redundant Recording and Capture
Purpose
Enabling redundant recording and capture, which means saving the record files and captured
pictures not only in the R/W HDD but also in the redundant HDD, will effectively enhance the data
safety and reliability.
Before you start
You must set the Storage mode in the HDD advanced settings to Group before you set the HDD
property to Redundant. For detailed information, please refer to Chapter 14.3 Managing HDD
Group. There should be at least another HDD which is in Read/Write status.
Step 1 Enter HDD Information interface.
Menu> HDD
Figure 5-27 HDD General
Step 2 Select the HDD and click to enter the Local HDD Settings interface.
1) Set the HDD property to Redundant.

HIKVISION DS-7104HGHI-F1/N Specifications

General

Power consumption (typical)	8 W
Voltage	12 V
Product color	White
Channels quantity	4 channels
Audio formats supported	G.711
Video compression formats	H.264, H.264+
BNC input ports	1
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	200 mm
Height	45 mm
Weight	800 g
