HIKVISION DS-7104HGHI-F1/N User Manual

Digital Video Recorder User Manual
202
Example: http://www.hik-online.com/nvr
If you mapped the HTTP port on your router and changed it to port No. except 80, you have to
enter http://www.hik-online.com/alias:HTTP port in the address bar to access the device. You can
refer to Chapter 12.2.7 Configuring HTTPS Port for the mapped HTTP port No..
 OPTION 2: Access the devices via iVMS-4200
For iVMS-4200, in the Add Device window, select and then edit the device
information.
Nickname: Edit a name for the device as you want.
Server Address: www. hik-online.com
Device Domain Name: It refers to the Device Domain Name on the device or the
Device Name on the HiDDNS server you created.
User Name: Enter the user name of the device.
Password: Enter the password of the device.
Figure 12-12 Access Device via iVMS-4200
Step 5 Click the Apply button to save and exit the interface.
12.2.4 Configuring NTP Server
Purpose
A Network Time Protocol (NTP) Server can be configured on your DVR to ensure the accuracy of
system date/time.
Step 1 Enter the Network Settings interface.
Menu > Configuration > Network
Step 2 Select the NTP tab to enter the NTP Settings interface.

HIKVISION DS-7104HGHI-F1/N Specifications

General

Power consumption (typical)	8 W
Voltage	12 V
Product color	White
Channels quantity	4 channels
Audio formats supported	G.711
Video compression formats	H.264, H.264+
BNC input ports	1
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	200 mm
Height	45 mm
Weight	800 g
