HIKVISION DS-7604NI-K1 User Manual

Network Video Recorder User Manual
197
12.2 Configuring Advanced Settings
12.2.1 Configuring Hik-Connect
Purpose
Hik-Connect enables the mobile phone application and the service platform page
(www.hik-connect.com) to access and manage your connected NVR, providing a convenient
remote access to the surveillance system.
The Hik-Connect can be enabled via operation on SADP software, GUI and Web browser. We
introduce the operation steps on GUI in this section.
Step 1 Enter the Network Settings interface.
Menu > Configuration > Network
Step 2 Select the Platform Access tab to enter the Hik-Connect Settings interface.
Figure 12-2 Hik-Connect Settings
Step 3 Check the Enable checkbox to activate the function. The Service Terms interface pops up as
below.

HIKVISION DS-7604NI-K1 Specifications

General

PTZ control	Yes
Display modes	Full screen, Live view, Playback, Split scren
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Throughput data rate	40 Mbit/s
Video input channels	4 channels
Supported resolutions	3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Resolution at capture speed	1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
Built-in display	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Product color	Black
Rack capacity	1U
Operating temperature (T-T)	-10 - 55 °C
Output voltage	12 V

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
