Network Video Recorder User Manual
96
2. Check UPnP.
3. Select Mapping Type as Manual or Auto.
– If you select Auto, the Port Mapping items are read-only, and the external ports are set by
the router automatically.
– If you select Manual as the mapping type, you can edit the external port on your demand by
clicking to activate the External Port Settings dialog box.
Note
● External Port indicates the port No. for port mapping in the router.
● The value of the RTSP port No. should be 554 or between 1024 and 65535, while the value
of the other ports should be between 1 and 65535 and the value must be different from
each other. If multiple devices are configured for the UPnP™ settings under the same
router, the value of the port No. for each device should be unique.
4. Enter the virtual server setting page of router; fill in the blank of Internal Source Port with the
internal port value, the blank of External Source Port with the external port value, and other
required contents.
Figure 8-6 Setting Virtual Server Item
● Each item should be corresponding with the device port, including server port, http port,
RTSP port and https port.
● The above virtual server setting interface is for reference only, it may be different due to
different router manufactures. Please contact the manufacture of router if you have any
problems with setting virtual server.
8.4 Check Network Traffic
You can check the network traffic to obtain real-time information of NVR such as linking status,
MTU, sending/receiving rate, etc.
Steps
1. Go to Menu → Maintenance → Net Detect.
