Network Video Recorder User Manual
22
3.2.2 Use an Auxiliary Monitor
Certain features of the Live View are also available while in an Aux monitor.
These features include:
● Single Screen: Switch to a full screen display of the selected camera. Camera can be selected
from a dropdown list.
● Multi-screen: Switch between different display layout options. Layout options can be selected
from a dropdown list.
● Next Screen: When displaying less than the maximum number of cameras in Live View, clicking
this feature will switch to the next set of displays.
● Playback: Enter into Playback mode.
● PTZ Control: Enter PTZ Control mode.
● Main Monitor: Enter Main operation mode.
Note
In the live view mode of the main output monitor, the menu operation is not available while Aux
output mode is enabled.
3.2.3 Quick Setting Toolbar in Live View Mode
On the screen of each channel, there is a quick setting toolbar which shows when you single click
the mouse in the corresponding screen.
Figure 3-2 Quick Setting Toolbar
Table 3-3 Description of Live View Icons
Instant Playback only shows the record in last five minutes. If no record is found, it means
there is no record during the last five minutes.
Digital Zoom is for zooming in the live image. You can zoom in the image to different
