EURO 46 V10 Programming Manual
Choose Mode Programming
1. Press b or  to scroll to ‘CHOOSE MODE’. Press
.
2. Press b or d to select the ‘EOL Range’ for all
wired inputs*, Then press .
3. Press b or d to select the ‘EOL Mode’ for all wired
inputs. Then press .
4. Press b or d to select the ‘Input Response’ for
all wired inputs*. Press  to return to the Engineer
Menu.
Install ZEMs?
Any Zone Expander Modules (ZEMs) installed on the EURO system must be enabled using the
‘INSTALL ZEM’ menu function.
ZEM Address
[0] ZEM Address 0 (Inputs 9-16) [1] ZEM Address 1 (Inputs 17-24)
[2] ZEM Address 2 (Inputs 25-32) [3] ZEM Address 3 (Inputs 33-40)
[4] ZEM Address 4 (Inputs 41-48) [5] ZEM Address 5 (Inputs 49-56)
[6] ZEM Address 6 (Inputs 57-64) [7] ZEM Address 7 (Inputs 65-72)
ZEM Installed
[0] No [1] ZEM8 / EURO37R [2] ZEM32-WE
Enter Location
The text entered here will be displayed on the LCD display if a fault occurs on the ZEM, so the ZEM
can be easily located or referenced.
Install ZEMs Programming
1. Press b or  to scroll to ‘INSTALL ZEMs?’.Press
.
2. Press b or d to select the ‘ZEM Address’ . Press
.
3. Press b or d to select either ‘ZEM8/EURO37R’,
‘ZEM32-WE’ or ‘No’ to ‘ZEM Installed’. Press .
4. Enter the location of the ZEM. Press  to return to
ZEM addressing.
CHOOSE MODE?
EOL Range
4K7/2K2 [1]
EOL MODE
DR [1]
Input Response
100ms [01]
INSTALL ZEMs?
ZEM Address
[0]
ZEM Installed
No [0]
Enter Location
_
