35
EURO 46 V10 Programming Manual
Wired Keypad Menu
The keypads have a small internal menu used mainly for: addressing, changing the key click volume
and changing the brightness of the LCD display.
Entering and Exiting the Keypad Menu
To enter the Keypad Menu, press and hold the d button until ‘SECURITY CODE:’ is displayed,
enter ‘2000’. To exit, press the a key.
Keypad Menu Options
ADDRESS - Used to assign an address to a keypad.
LANGUAGE - Allows you to assign a language to the keypad menu only
ZONE STATUS - Displays the resistance of the two hard wired inputs to the keypad terminals.
KEY-CLICK VOLUME - Alters the volume of the tone heard when a keypad button is pressed.
TAG VOLUME - Sets the volume when tag is presented
KEYPAD VOLUME - Sets the general volume of the keypad
ID TAG - Used to read the unique ID number of the tag
RESET KEYPAD - Resets the keypad to factory settings
BACKLIGHT FORCE - Change to ‘1’ to force the LCD back-light on all the time. If left on ‘0’, the LCD
will dim after 30 seconds.
PA/FIRE Timer - Sets how long the HU and Fire buttons have to be pressed for before an alarm is
generated
Testing the Keypad
With the system unset, press and hold the b key for 10 seconds at any keypad. This will cause all
the LEDs on that keypad to illuminate and the LCD screen to display each pixel. Approximately 10
seconds after the b key is released, the keypad will revert to the normal display.
