15
EURO 46 V10 Programming Manual
5. Press to return to the Engineers menu.
PLEASE NOTE: If using wireless bells, Wireless Arming Stations or key fobs, the wireless ZEM has to
be addressed as 00.
Change Outputs?
This option enables the programming of the outputs on the EURO 46 V10 and any devices that are
connected to it. For a full list of output types please refer to ‘Appendix 2’.
Endstation Outputs?
These are the outputs on the control panel itself: BELL O/P, STB O/P, PGM O/P, XPGM1 O/P, XPGM2
O/P, and ATE PINS 1-9. All of these are programmable but at default the BELL and STB are allocated
to follow the alarm in any area as bell and strobe.
ZEM Outputs?
These are the outputs that are located in the ZEM8+ or ZEM8+PSU input expander modules, if used,
there are four PGMs located on each of these modules.
Wireless Bells?
These are the wireless bell outputs of the ZEM32-WE if installed. There are two outputs – BELL O/P
and STB O/P both of which are programmable.
Output Module Outputs?
This option enables the addition of a wired output module to the Control Panel, as well as
programming of the PGM options for the outputs on the module.
Keypad Outputs?
Allows the programming of the PGM options for the outputs located on the wired keypads.
Reader Outputs?
Allows the programming of the PGM options for the outputs located on the wired readers.
User Outputs?
These outputs are used for creating automation control for devices. The user can control them
remotely from the user menu on the keypad or via the HomeControl+ smart phone APP. The
automated user outputs can be programmed (either latched or timed).
Polarity of the PGMs: The polarity of the outputs are normally switched negative, i.e. normal status
OFF = 12VDC and in active status ON = 0VDC.
PLEASE NOTE: The PGM Outputs polarity cannot be inverted.
Assign Keypads and Readers?
Ensure that all keypads and readers are addressed correctly (at the device) before enabling and
addressing them in this function. To address at the device please refer to the installation reference
manual.
PLEASE NOTE: At least one keypad/reader should have the ability to unset any areas programmed.
Address /Arming Station Address
Addresses from 00 - 05 allow allocation of external wired readers or keypads, and 06 - 09 are for
Wireless Arming Stations.
