EURO 46 V10 Programming Manual
Options Programmable Only From PC
The UDL software is available on www.pyronix.com/downloads. The software can be used to upload/
download to the Control Panel and data can be viewed.
Two features that the UDL software incorporates are:
• Auto Set and Unset Timer
• Logic Gates
For help in the initial software set up, please refer to the UDL software help guides first.
Auto Set/Unset Timers
This function will allow automatic setting and unsetting procedures. This is useful when a premises is
left unmanned for a period of time (such as holidays).
Create a new customer and select ‘Euro’ and then scroll to EURO 46 V10
The Auto-Set/Logic Gates will be enabled, click the ‘OK’ button.
Adding Set/Unset actions
1. Select ‘Add Action’.
2. Select the Day of the week to be Auto-Set. This will
then be displayed in the list.
3. Select the action of this timer (such as Set)
4. Select the time (24 hour, such as 14:00 NOT 02:00)
when the action should start.
5. Another action can now be added (such as Unset)
and select the time for this action.
Adding ‘Holidays’
A holiday setting will override any auto-timers that
coincide with the holiday. Once the holiday has passed,
it will not repeat.
1. Click ‘Add Holiday’
2. Select the dates that are required for the holiday
period. These will be displayed at the top right of
the screen under ‘Date’.
3. If any holidays are added by mistake, select that
holiday and click ‘delete’.
PLEASE NOTE: Make sure that any action already programmed matches correctly when the holiday
period has finished, such as: if the dates January 1st, January 2nd, and January 3rd are selected,
the Control Panel will stay set on all of the dates regardless of the auto-timers. However, an auto-timer
should be set up to unset the day after the holiday has ended if required.
